MXL 1~10k

The MXL UPS is an online double conversion UPS available from 1kVA to 10kVA with an output power factor 1. It is compatible with a wide range of battery autonomies enabling it to provide long backup times whenever necessary. The MXL series is designed to provide continuous utility power protection for critical system installation. It has USB and RS-232 communication ports as standard, with a built-in intelligent slot for optional protocol converters (e.g. SNMP…)

Best Suited for: Banking, financial and insurance, data center, education, healthcare, government

DOCUMENTS & DOWNLOADS

LEAFLET

DOCUMENTS & DOWNLOADS

LEAFLET

DOCUMENTS & DOWNLOADS

LEAFLET
Description
  • True Online Double Conversion Design
  • Pure Sine Wave Output
  • Fully Digitized Microprocessor Control
  • DSP Technology
  • Output Power Factor 1
  • Active Input Power Factor Correction (PFC 0.99)
  • 50/60 Hz Frequency Converter
  • Wide Input Voltage Range
  • Cold Start Function (DC Power On)
  • Advanced Battery Management (ABM Technology)
  • Automatic Diagnostics & Battery Check
  • High Overload Capability and Enhanced Short Circuit Protection
  • Eco Mode For Energy Saving
  • Isolation Transformer*
  • Programmable Power Management Outlets
  • Multi-Function LCD Display

 * Optional Features

DOCUMENTS & DOWNLOADS

LEAFLET
Specifications


ModelMXL 1k

Input
Rating
Voltage
Frequency
Voltage range
Power Factor
THDi
1000VA
220V, 230V, 240V, 1Ø 2Wires
40Hz~70Hz
160-300 VAC at 100% load, 110-300 VAC at 50% load
>99%
≤3%

Ouput
Output Power with cosφ=1
Voltage (on battery)
Frequency (on battery)
Transfer Time
UPS Design Technology
Output Wave Form
Total Harmonic distortion (THD)
Crest Factor
1000W
220V, 230V, 240V, +/-1% (selectable output voltage), 1Ø 2Wires
50/60 Hz +/-0.1%
0 ms
Online double conversion design
Pure Sinewave
≤2% (linear load), ≤4% (non linear load)
3:1

Protection
Overload Protection
Short Circuit Protection
110% for 10min, 130% for 1min, >130% for 3sec
UPS output cut off immediately using input fuse/circuit breaker protection

Efficiency
AC Mode
Battery Mode
95%
93%

System Display
LCD indicators
UPS status, load level, battery level, input/output voltage, discharge time and fault indicators

Alarm
Battery mode
Low battery
Overload
Fault
Sounding every 4 second
Sounding every second
Sounding twice every second
Continuously sounding

Battery
Battery Type
Typical Recharge Time
Charging Current
DC Voltage
Extended Back up time
SLA, Nicad, Li-ion
Depending on capacity of external batteries
1-2-4-6A (adjustable)
36 VDC
Longer backup time depending on extra battery pack

Communication
USB, RS-232, AS-400**
SNMP**
Compatibility
Interface with power management software
Power Management from SNMP manager and web browser
Supports Windows family, Linux, Unix and Mac

Physical
Dimension, WxDxH mm
Net Weight Kgs
145 X 397 X 220
5.8

Environment
Ambient operation
Audible noise
Maximum elevation at 1000m, 0 to 40°C, 20 to 90% humidity (non-condensing)
<50dBA at 1 Meter

Standards & Certifications
Performance
Safety
EMC (EMS / EMI)
Design, production, & services
Environment
Marking & Certifications
EN50091-3/IEC 62040-3
UL 1778, CE, EN 50091-1,EN 60950 (RD/), IEC 60950
IEC 61000-4-2/-3/-4/-5/-6/-8/-11, IEC 61000-3-2/-3,FCC Part 15, CISPR 22, EN 50091-2/IEC62040-2 Class A, EN 55022/B,FCC 47 part 15 - Subpart B -
ISO 9001
ISO 14001 certified company
CE, TUV/GS, UL, cUL, c-Tick

* NOTE 1: Derate to 60% of capacity in CVCF mode and to 90% when the output voltage is adjusted to 208VAC.
NOTE 2: If the UPS is installed or used in a place where the altitude is above than the rated altitude, the output power must be derated one percent per 100m.
** For optional features
***Product specifications are subject to change without further notice
ModelMXL 2k

Input
Rating
Voltage
Frequency
Voltage range
Power Factor
THDi
2000VA
220V, 230V, 240V, 1Ø 2Wires
40Hz~70Hz
160-300 VAC at 100% load, 110-300 VAC at 50% load
>99%
≤3%

Ouput
Output Power with cosφ=1
Voltage (on battery)
Frequency (on battery)
Transfer Time
UPS Design Technology
Output Wave Form
Total Harmonic distortion (THD)
Crest Factor
2000W
220V, 230V, 240V, +/-1% (selectable output voltage), 1Ø 2Wires
50/60 Hz +/-0.1%
0 ms
Online double conversion design
Pure Sinewave
≤2% (linear load), ≤4% (non linear load)
3:1

Protection
Overload Protection
Short Circuit Protection
110% for 10min, 130% for 1min, >130% for 3sec
UPS output cut off immediately using input fuse/circuit breaker protection

Efficiency
AC Mode
Battery Mode
95%
94%

System Display
LCD indicators
UPS status, load level, battery level, input/output voltage, discharge time and fault indicators

Alarm
Battery mode
Low battery
Overload
Fault
Sounding every 4 second
Sounding every second
Sounding twice every second
Continuously sounding

Battery
Battery Type
Typical Recharge Time
Charging Current
DC Voltage
Extended Back up time
SLA, Nicad, Li-ion
Depending on capacity of external batteries
1-2-4-6A (adjustable)
72 VDC
Longer backup time depending on extra battery pack

Communication
USB, RS-232, AS-400**
SNMP**
Compatibility
Interface with power management software
Power Management from SNMP manager and web browser
Supports Windows family, Linux, Unix and Mac

Physical
Dimension, WxDxH mm
Net Weight Kgs
190 X 421 X 318
12

Environment
Ambient operation
Audible noise
Maximum elevation at 1000m, 0 to 40°C, 20 to 90% humidity (non-condensing)
<50dBA at 1 Meter

Standards & Certifications
Performance
Safety
EMC (EMS / EMI)
Design, production, & services
Environment
Marking & Certifications
EN50091-3/IEC 62040-3
UL 1778, CE, EN 50091-1,EN 60950 (RD/), IEC 60950
IEC 61000-4-2/-3/-4/-5/-6/-8/-11, IEC 61000-3-2/-3,FCC Part 15, CISPR 22, EN 50091-2/IEC62040-2 Class A, EN 55022/B,FCC 47 part 15 - Subpart B -
ISO 9001
ISO 14001 certified company
CE, TUV/GS, UL, cUL, c-Tick

* NOTE 1: Derate to 60% of capacity in CVCF mode and to 90% when the output voltage is adjusted to 208VAC.
NOTE 2: If the UPS is installed or used in a place where the altitude is above than the rated altitude, the output power must be derated one percent per 100m.
** For optional features
***Product specifications are subject to change without further notice


ModelMXL 3k

Input
Rating
Voltage
Frequency
Voltage range
Power Factor
THDi
3000VA
220V, 230V, 240V, 1Ø 2Wires
40Hz~70Hz
160-300 VAC at 100% load, 110-300 VAC at 50% load
>99%
≤3%

Ouput
Output Power with cosφ=1
Voltage (on battery)
Frequency (on battery)
Transfer Time
UPS Design Technology
Output Wave Form
Total Harmonic distortion (THD)
Crest Factor
3000W
220V, 230V, 240V, +/-1% (selectable output voltage), 1Ø 2Wires
50/60 Hz +/-0.1%
0 ms
Online double conversion design
Pure Sinewave
≤2% (linear load), ≤4% (non linear load)
3:1

Protection
Overload Protection
Short Circuit Protection
110% for 10min, 130% for 1min, >130% for 3sec
UPS output cut off immediately using input fuse/circuit breaker protection

Efficiency
AC Mode
Battery Mode
95%
94%

System Display
LCD indicators
UPS status, load level, battery level, input/output voltage, discharge time and fault indicators

Alarm
Battery mode
Low battery
Overload
Fault
Sounding every 4 second
Sounding every second
Sounding twice every second
Continuously sounding

Battery
Battery Type
Typical Recharge Time
Charging Current
DC Voltage
Extended Back up time
SLA, Nicad, Li-ion
Depending on capacity of external batteries
1-2-4-6A (adjustable)
72VDC
Longer backup time depending on extra battery pack

Communication
USB, RS-232, AS-400**
SNMP**
Compatibility
Interface with power management software
Power Management from SNMP manager and web browser
Supports Windows family, Linux, Unix and Mac

Physical
Dimension, WxDxH mm
Net Weight Kgs
190 X 421 X 318
13.8

Environment
Ambient operation
Audible noise
Maximum elevation at 1000m, 0 to 40°C, 20 to 90% humidity (non-condensing)
<50dBA at 1 Meter

Standards & Certifications
Performance
Safety
EMC (EMS / EMI)
Design, production, & services
Environment
Marking & Certifications
EN50091-3/IEC 62040-3
UL 1778, CE, EN 50091-1,EN 60950 (RD/), IEC 60950
IEC 61000-4-2/-3/-4/-5/-6/-8/-11, IEC 61000-3-2/-3,FCC Part 15, CISPR 22, EN 50091-2/IEC62040-2 Class A, EN 55022/B,FCC 47 part 15 - Subpart B -
ISO 9001
ISO 14001 certified company
CE, TUV/GS, UL, cUL, c-Tick

* NOTE 1: Derate to 60% of capacity in CVCF mode and to 90% when the output voltage is adjusted to 208VAC.
NOTE 2: If the UPS is installed or used in a place where the altitude is above than the rated altitude, the output power must be derated one percent per 100m.
** For optional features
***Product specifications are subject to change without further notice




ModelMXL 6k

Input
Rating
Voltage
Frequency
Voltage range
Power Factor
THDi
6000VA
220V, 230V, 240V, 1Ø 2Wires
40Hz~70Hz
160-300 VAC at 100% load, 110-300 VAC at 50% load
>99%
≤3%

Ouput
Output Power with cosφ=1
Voltage (on battery)
Frequency (on battery)
Transfer Time
UPS Design Technology
Output Wave Form
Total Harmonic distortion (THD)
Crest Factor
6000W
220V, 230V, 240V, +/-1% (selectable output voltage), 1Ø 2Wires
50/60 Hz +/-0.1%
0 ms
Online double conversion design
Pure Sinewave
≤3% (linear load), ≤5% (non linear load)
3:1

Protection
Overload Protection
Short Circuit Protection
110% for 10min, 130% for 1min, >130% for 1sec
UPS output cut off immediately using input fuse/circuit breaker protection

Efficiency
AC Mode
Battery Mode
>95%
>94%

System Display
LCD indicators
UPS status, load level, battery level, input/output voltage, discharge time and fault indicators

Alarm
Battery mode
Low battery
Overload
Fault
Sounding every 4 second
Sounding every second
Sounding twice every second
Continuously sounding

Battery
Battery Type
Typical Recharge Time
Charging Current
DC Voltage
Extended Back up time
SLA, Nicad, Li-ion
Depending on capacity of external batteries
4A +/-10%
240VDC
Longer backup time depending on extra battery pack

Communication
USB, RS-232, AS-400**
SNMP**
Compatibility
Interface with power management software
Power Management from SNMP manager and web browser
Supports Windows family, Linux, Unix and Mac

Physical
Dimension, WxDxH mm
Net Weight Kgs
250 x 592 x 576
25

Environment
Ambient operation
Audible noise
Maximum elevation at 1000m, 0 to 40°C, 0 to 95% humidity (non-condensing)
<55dBA at 1 Meter

Standards & Certifications
Performance
Safety
EMC (EMS / EMI)
Design, production, & services
Environment
Marking & Certifications
EN50091-3/IEC 62040-3
UL 1778, CE, EN 50091-1,EN 60950 (RD/), IEC 60950
IEC 61000-4-2/-3/-4/-5/-6/-8/-11, IEC 61000-3-2/-3,FCC Part 15, CISPR 22, EN 50091-2/IEC62040-2 Class A, EN 55022/B,FCC 47 part 15 - Subpart B -
ISO 9001
ISO 14001 certified company
CE, TUV/GS, UL, cUL, c-Tick

* NOTE 1: Derate to 60% of capacity in CVCF mode and to 90% when the output voltage is adjusted to 208VAC.
NOTE 2: If the UPS is installed or used in a place where the altitude is above than the rated altitude, the output power must be derated one percent per 100m.
** For optional features
***Product specifications are subject to change without further notice


ModelMXL 10k

Input
Rating
Voltage
Frequency
Voltage range
Power Factor
THDi
10000VA
220V, 230V, 240V, 1Ø 2Wires
40Hz~70Hz
160-300 VAC at 100% load, 110-300 VAC at 50% load
>99%
≤3%

Ouput
Output Power with cosφ=1
Voltage (on battery)
Frequency (on battery)
Transfer Time
UPS Design Technology
Output Wave Form
Total Harmonic distortion (THD)
Crest Factor
10000W
220V, 230V, 240V, +/-1% (selectable output voltage), 1Ø 2Wires
50/60 Hz +/-0.1%
0 ms
Online double conversion design
Pure Sinewave
≤3% (linear load), ≤5% (non linear load)
3:1

Protection
Overload Protection
Short Circuit Protection
110% for 10min, 130% for 1min, >130% for 1sec
UPS output cut off immediately using input fuse/circuit breaker protection

Efficiency
AC Mode
Battery Mode
>96%
>95%

System Display
LCD indicators
UPS status, load level, battery level, input/output voltage, discharge time and fault indicators

Alarm
Battery mode
Low battery
Overload
Fault
Sounding every 4 second
Sounding every second
Sounding twice every second
Continuously sounding

Battery
Battery Type
Typical Recharge Time
Charging Current
DC Voltage
Extended Back up time
SLA, Nicad, Li-ion
Depending on capacity of external batteries
4A +/-10%
240VDC
Longer backup time depending on extra battery pack

Communication
USB, RS-232, AS-400**
SNMP**
Compatibility
Interface with power management software
Power Management from SNMP manager and web browser
Supports Windows family, Linux, Unix and Mac

Physical
Dimension, WxDxH mm
Net Weight Kgs
250 x 592 x 576
27

Environment
Ambient operation
Audible noise
Maximum elevation at 1000m, 0 to 40°C, 0 to 95% humidity (non-condensing)
<58dBA at 1 Meter

Standards & Certifications
Performance
Safety
EMC (EMS / EMI)
Design, production, & services
Environment
Marking & Certifications
EN50091-3/IEC 62040-3
UL 1778, CE, EN 50091-1,EN 60950 (RD/), IEC 60950
IEC 61000-4-2/-3/-4/-5/-6/-8/-11, IEC 61000-3-2/-3,FCC Part 15, CISPR 22, EN 50091-2/IEC62040-2 Class A, EN 55022/B,FCC 47 part 15 - Subpart B -
ISO 9001
ISO 14001 certified company
CE, TUV/GS, UL, cUL, c-Tick

* NOTE 1: Derate to 60% of capacity in CVCF mode and to 90% when the output voltage is adjusted to 208VAC.
NOTE 2: If the UPS is installed or used in a place where the altitude is above than the rated altitude, the output power must be derated one percent per 100m.
** For optional features
***Product specifications are subject to change without further notice



Related products

M8 Series

,

MXL31 10~20K

,

MXL33 10~60k

,

VX 1~10K

,

MXRM 1~10K

,

MX31 10~20K

,

MX33 10~40k

,

MXRM31 10~20K

,
